ST1CC40PUR

ST1CC40PUR Overview

Product belongs to the ST1CC40 series. Type: DC DC Regulator Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style VFQFPN-8 This product's 850kHz range is 0Hz to 2.2GHz. Operational temperature range: -40°C ~ 150°C (TJ) Surface Mount mounting type Versatile Lighting, Signage applications for maximum usability Supplier device package: 8-VFQFPN (4x4) Number-of-Outputs: 1 Current-Output-Channel is 3A This product has Yes. Topology: Step-Down (Buck) feedback The maximum voltage supply is 18V. The minimum 3V required for voltage supply. Output voltage: - Dimming control is done through - communication. 1.5 mA is 92 nA. Maximum Input Voltage: 18 V Output current: 3 A Switching frequency is 850 kHz The product's 3 V is 5.1 V.

ST1CC40PUR Image

ST1CC40PUR Specifications

• Manufacturer STMicroelectronics
• Product Category PMIC - LED Drivers
• Series ST1CC40
• Type DC DC Regulator
• Packaging Digi-ReelR Alternate Packaging
• Mounting-Style SMD/SMT
• Package-Case VFQFPN-8
• Frequency 850kHz
• Operating-Temperature -40°C ~ 150°C (TJ)
• Mounting-Type Surface Mount
• Applications Lighting, Signage
• Supplier-Device-Package 8-VFQFPN (4x4)
• Number-of-Outputs 1
• Current-Output-Channel 3A
• Internal-Switch-s Yes
• Topology Step-Down (Buck)
• Voltage-Supply-Max 18V
• Voltage-Supply-Min 3V
• Voltage-Output -
• Dimming -
• Operating-Supply-Current 1.5 mA
• Input-Voltage-MAX 18 V
• Output-Current 3 A
• Switching-Frequency 850 kHz
• Input-Voltage-MIN 3 V
