LM1558H

LM1558H Overview

Product belongs to the LM1558 series. This product is categorized as Operational Amplifiers Bulk is the packaging method for this product Through Hole Mounting-Style Bipolar is the technology used. Number of channels: 2 Channel Power-off control: No Shutdown Maximum operating temperature of + 125 C Minimum operating temperature: - 55 C 5 mA is 92 nA. Maximum supply voltage of 44 V Minimum supply voltage is 6 V TO-99-8 Input bias current of 1.5 uA at +/- 15 V The 5 mV. The 77 dB. The CMRR-Common-Mode-Rejection-Ratio is 70 dB. The 30 nV/sqrt Hz of this product is 110 nV/sqrt Hz. The 0.15 pA/sqrt Hz. Maximum dual supply voltage: +/- 22 V Minimum dual supply voltage of +/- 3 V

LM1558H Image

LM1558H Specifications

• Manufacturer
• Product Category Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
• Series LM1558
• Product Operational Amplifiers
• Packaging Bulk
• Mounting-Style Through Hole
• Technology Bipolar
• Number-of-Channels 2 Channel
• Shutdown No Shutdown
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 55 C
• Operating-Supply-Current 5 mA
• Supply-Voltage-Max 44 V
• Supply-Voltage-Min 6 V
• Package-Case TO-99-8
• Ib-Input-Bias-Current 1.5 uA at +/- 15 V
• Vos-Input-Offset-Voltage 5 mV
• PSRR-Power-Supply-Rejection-Ratio 77 dB
• CMRR-Common-Mode-Rejection-Ratio 70 dB
• GBP-Gain-Bandwidth-Product 1 MHz
• SR-Slew-Rate 0.5 V/us
• en-Input-Voltage-Noise-Density 30 nV/sqrt Hz
• In-Input-Noise-Current-Density 0.15 pA/sqrt Hz
• Maximum-Dual-Supply-Voltage +/- 22 V
• Minimum-Dual-Supply-Voltage +/- 3 V
