HMC1131LC4

HMC1131LC4 Overview

Product belongs to the - series. Type: Medium Power Amplifier Cut Strip Alternate Packaging is the packaging method for this product Weight of 0.032741 oz SMD/SMT Mounting-Style QFN-24 This product's 24GHz ~ 35GHz range is 0Hz to 2.2GHz. GaAs is the technology used. Frequency Bandwidth: 24 GHz to 35 GHz Number of channels: 1 Channel Voltage Supply Range: 5V Supplier device package: 24-SMT (4x4) This product has a 225mA of 200μA. The device offers a 24dB of 26dB. The amplifier is of Driver Amplifier type. Test-Frequency is 24GHz ~ 27GHz. P1dB is 24dBm RF-Type: VSAT Power-off control: 1.97 W Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C This product operates at a 5 V supply voltage for reliable performance. 225 mA is 92 nA. The operating frequency is 24 GHz to 35 GHz. The EV1HMC1131LC4. NF-Noise-Figure is - 35 dBm OIP3 third-order intercept The 8 dB is 12 dB.

HMC1131LC4 Image

HMC1131LC4 Specifications

• Manufacturer Analog Devices Inc.
• Product Category RF Amplifiers
• Series -
• Type Medium Power Amplifier
• Packaging Cut Strip Alternate Packaging
• Unit-Weight 0.032741 oz
• Mounting-Style SMD/SMT
• Package-Case QFN-24
• Frequency 24GHz ~ 35GHz
• Technology GaAs
• Frequency-Range 24 GHz to 35 GHz
• Number-of-Channels 1 Channel
• Voltage-Supply 5V
• Supplier-Device-Package 24-SMT (4x4)
• Current-Supply 225mA
• Gain 24dB
• Amplifier-Type Driver Amplifier
• Test-Frequency 24GHz ~ 27GHz
• P1dB 24dBm
• Noise-Figure -
• RF-Type VSAT
• Pd-Power-Dissipation 1.97 W
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Voltage 5 V
• Operating-Supply-Current 225 mA
• Operating-Frequency 24 GHz to 35 GHz
• Development-Kit EV1HMC1131LC4
• NF-Noise-Figure -
• P1dB-Compression-Point 24 dBm
• OIP3-Third-Order-Intercept 35 dBm
• Input-Return-Loss 8 dB
