AD8611ARMZ-R2 Overview

Product belongs to the AD8611 series. This product is categorized as Analog Comparators Type: with Latch Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.004938 oz SMD/SMT Mounting-Style MSOP-8 Operational temperature range: -40°C ~ 85°C Surface Mount mounting type Output-Type: Complementary, TTL Number of channels: 1 Channel Supplier device package: 8-MSOP Voltage supply range: 3 V ~ 5 V 1 element 10mA, 4mA maximum quiescent current. Maximum propagation delay: 5.5ns Hysteresis value of - 5.5 ns response time Power-off control: No Shutdown Power-off control: 50 mW Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C 10 mA is 92 nA. Maximum supply voltage of 5 V Minimum supply voltage is 3 V Complementary with Latch comparator type Input bias current of 6 uA The 7 mV. 5.5 ns is 23 microseconds. The 73 dB. 10 mA The CMRR-Common-Mode-Rejection-Ratio is 85 dB.

AD8611ARMZ-R2 Image

AD8611ARMZ-R2 Specifications

• Manufacturer ANALOG DEVICES
• Product Category Linear - Comparators
• Series AD8611
• Product Analog Comparators
• Type with Latch
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.004938 oz
• Mounting-Style SMD/SMT
• Package-Case MSOP-8
• Operating-Temperature -40°C ~ 85°C
• Mounting-Type Surface Mount
• Output-Type Complementary, TTL
• Number-of-Channels 1 Channel
• Supplier-Device-Package 8-MSOP
• Voltage-Supply-Single-Dual 3 V ~ 5 V
• Number-of-Elements 1
• Voltage-Input-Offset-Max 7mV @ 5V
• Current-Input-Bias-Max 6μA @ 5V
• Current-Output-Typ -
• Current-Quiescent-Max 10mA, 4mA
• CMRR-PSRR-Typ 85dB CMRR, 73dB PSRR
• Propagation-Delay-Max 5.5ns
• Hysteresis -
• Response-Time 5.5 ns
• Shutdown No Shutdown
• Pd-Power-Dissipation 50 mW
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Current 10 mA
• Supply-Voltage-Max 5 V
• Supply-Voltage-Min 3 V
• Comparator-Type Complementary with Latch
• Ib-Input-Bias-Current 6 uA
• Vos-Input-Offset-Voltage 7 mV
• Propagation-Delay-Time 5.5 ns
• PSRR-Power-Supply-Rejection-Ratio 73 dB
• Output-Current-per-Channel 10 mA
• CMRR-Common-Mode-Rejection-Ratio 85 dB
• GBP-Gain-Bandwidth-Product -
• SR-Slew-Rate -
