SN74HC153AN

SN74HC153AN Overview

This product is manufactured by ON Semiconductor. Decoders, Encoders, Multiplexers & Demultiplexers The product uses the 74LC logic family. Number of bits: 4 bit The propagation delay time is 7.5 ns at 2.7 V, 6.5 ns at 3 V. Supply Voltage - Min: 2 V Supply Voltage - Max: 3.6 V The minimum operating temperature of this product is - 40 C. The product can operate at a maximum temperature of + 85 C. The product can operate at a maximum temperature of SMD/SMT. TSSOP-16 package/case type is utilized by this product. Tube packaging for easy dispensing t's a Multiplexer The height of the product is 1.05 mm. 5.1 mm long This product has Quad circuit. ON Semiconductor is a trusted brand for quality electronics Multiplexer. This product has a - 24 mA, ensuring reliable performance in demanding applications. Low Level Output Current is 24 mA - 0.5 V to + 7 V operating supply voltage range Encoders, Decoders, Multiplexers & Demultiplexers product type 96 of 100 Logic ICs as subcategory 1. 0.006102 oz of Unit Weight

SN74HC153AN Image

SN74HC153AN Specifications

• Manufacturer: ON Semiconductor
• Product Category: Encoders, Decoders, Multiplexers & Demultiplexers
• RoHS: Y
• Product: Decoders, Encoders, Multiplexers & Demultiplexers
• Logic Family: 74LC
• Number of Bits: 4 bit
• Number of Input Lines: 2 Input
• Number of Output Lines: 4 Output
• Propagation Delay Time: 7.5 ns at 2.7 V, 6.5 ns at 3 V
• Supply Voltage - Min: 2 V
• Supply Voltage - Max: 3.6 V
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 85 C
• Mounting Style: SMD/SMT
• Package / Case: TSSOP-16
• Packaging: Tube
• Function: Multiplexer
• Height: 1.05 mm
• Length: 5.1 mm
• Number of Circuits: Quad
• Series: MC74LCX158
• Technology: CMOS
• Width: 4.5 mm
• Brand: ON Semiconductor
• Logic Type: Multiplexer
• High Level Output Current: - 24 mA
• Low Level Output Current: 24 mA
• Operating Supply Voltage: - 0.5 V to + 7 V
• Product Type: Encoders, Decoders, Multiplexers & Demultiplexers
• Factory Pack Quantity: 96
• Subcategory: Logic ICs
• Unit Weight: 0.006102 oz
